Solid-State Decoupler for Cathodic Protection System
Product Introduction
We intention at becoming one among your most trusted partners and earning your fulfillment for Aluminum Alloy Cast Anode, GPS Current Interrupter, Canistered Cast Iron Anode. Only for accomplishing the good-quality product to meet customer's demand, all of our products have been strictly inspected before shipment. We have always kept our original intention and mission in mind, and actively assume social responsibility. We have now sophisticated machines. We pay special attention to our corporate responsibility and social obligation in environmental protection, and have established a perfect and comprehensive new product development system to actively seek sustainable development of our company and society.
Product introduction
In the cathodic protection system, solid state de-coupler as dc isolation and AC coupling device is not only used to prevent the cathodic protection current from reaching a predetermined threshold voltage, but also can conduct inductive alternating current.
- Product features:
- Stable performance: it is conductive to the coupled AC current on the pipeline, which can effectively reduce the induced AC interference voltage.
- Able to withstand the expected large impact: in the case of induced lightning or single-phase short circuit fault of power lines, it can withstand the expected large impact or fault current, and the fault state is short circuit mode.
- Wide range of application: adapt to field environmental conditions, meet the requirements of easy installation and maintenance on site.
- Long life: Reasonable use, service life can exceed 20 years.
- Product application:
- Transient, transient and long-term overvoltage protection.
- Solid state de-coupler can be used in electrified railway, high voltage AC transmission and distribution, substation, power plant and other AC interference sources to alleviate the ac interference of buried steel pipeline.
- Ac grounding and DC isolation of electrical equipment in the cathodic protection system.
product Parameter
| Technical parameters | |
| Rated isolation voltage | -2V/+2V(optional -3V/+1V, -2V/+0.4V) |
| Nominal discharge current (8/20us) | 100KA |
| Lightning impulse current (10/350us) | 50KA |
| Ac fault current | ≥3500A(optional: 5000A, 9000A) |
| Steady state ac current rating (±2V) | 50A |
| Dc leakage current | ≤1mA |
| Response time | 10ns |
| Protection level | IP65 |
| Explosion-proof grade | Exd II CT4 |
| Operating temperature range | -25 ℃ ~50℃ |
| Installation method | with explosion-proof box and bracket surface installation |
